产品型号 |
排气量 |
排气压力(MPa) |
电功功率(KW) |
气缸直径(MM) |
活塞行程(MM) |
外型尺寸(长×宽×高) |
WW-0.9/7 |
0.9 |
0.7 |
5.5 |
3×Φ110 |
68 |
1320×550×1200 |
WW-1.2/7 |
1.2 |
0.7 |
11 |
3×Φ110 |
68 |
1320×550×1200 |
WW-0.6/10 |
0.6 |
1.0 |
5.5 |
2×Φ110 1×Φ90 |
68 |
1320×550×1200 |
WW-0.9/10 |
0.9 |
1.0 |
7.5 |
2×Φ110 1×Φ90 |
68 |
1320×550×1200 |
WW-1.8/7-II |
1.8 |
0.7 |
2×7.5 |
6×Φ110 |
68 |
1200×1200×850 |
WW-2.4/7-II |
2.4 |
0.7 |
2×11 |
6×Φ110 |
68 |
1200×1200×850 |
WW-2.7/7-II |
2.7 |
0.7 |
3×7.5 |
9×Φ110 |
68 |
1800×1200×850 |
WW-1.2/10-II |
1.2 |
1.0 |
2×5.5 |
4×Φ110 2×Φ90 |
68 |
1200×1200×850 |
WW-1.8/10-II |
1.8 |
1.0 |
2×7.5 |
4×Φ110 2×Φ90 |
68 |
1200×1200×850 |
WW-2.7/10-II |
2.7 |
1.0 |
3×7.5 |
6×Φ110 3×Φ100 |
68 |
1800×1200×850 |
WW-1.2/10 |
1.2 |
1 |
11 |
2×Φ125 1×Φ110 |
75 |
1200×650×1200 |
WW-1.5/7 |
1.5 |
0.7 |
11 |
3×Φ125 |
75 |
1200×650×1200 |
WW-2.4/10-Ⅱ |
2.4 |
10 |
2×11 |
4×Φ125 2×Φ110 |
75 |
1500×1200×1350 |
WW-3/7-Ⅱ |
3 |
0.7 |
2×11 |
6×Φ125 |
75 |
1500×1200×1350 |
WW-3/7-Ⅲ |
3 |
0.7 |
3×7.5 |
9×Φ110 |
75 |
1800×1500×1350 |
WW-3/10-Ⅲ |
3 |
1 |
3×7.5 |
6×Φ110 3×Φ100 |
75 |
1800×1500×1350 |
WW-0.9/7-ⅹ |
0.9 |
0.7 |
7.5 |
3×Φ110 |
75 |
1200×600×980 |
WW-0.9/10-ⅹ |
0.9 |
1 |
7.5 |
2×Φ110 1×Φ100 |
75 |
1200×600×900 |
WW-0.7/14 |
0.7 |
1.4 |
5.5 |
2×Φ110 1×Φ90 |
75 |
1320×550×1200 |
WW-0.9/14 |
0.9 |
1.4 |
7.5 |
2×Φ110 1×Φ90 |
75 |
1320×550×1200 |
WW-1.2/14 |
1.2 |
1.4 |
11 |
2×Φ125 1×Φ110 |
75 |
1200×650×1200 |
WW-1.6/14 |
1.6 |
1.4 |
15 |
2×Φ125 1×Φ110 |
75 |
1200×650×1200 |
WW-1.8/7 |
1.8 |
0.7 |
15 |
3×Φ125 |
75 |
1200×650×1200 |
